Key Specifications
Overview of the technical specifications.
Operating Weight
24.39 ton
Engine Power
110 kW / 2000 rpm
Bucket Capacity
0.52 m³
Track Shoe Width
800 mm
| Parameter | HX220SLR |
|---|---|
| Operating weight(kg) | 24390 |
| Engine power(kW/rpm) | 110 / 2000 |
| Bucket capacity(m³) | 0.52 |
| External dimensions(mm) | 9650*2800*3000 |
| Bucket rod digging force(kN) | 50 |
| Bucket digging force(kN) | 83.4 |
| Rotating speed(r/min) | 10.8 |
| Travel speed(km/h) | 3.6 / 5.5 |
| Maximum digging height(mm) | 10280 |
| Maximum digging distance(mm) | 15220 |
| Maximum digging depth(mm) | 11760 |
| Emissions (Indicated as per international standards) | ~TIER 2 |
