Key Specifications
Overview of the technical specifications.
Operating Weight
30.2 ton
Engine Power
193 kW / 2200 rpm
Bucket Capacity
1.5 m³
Track Shoe Width
600 mm
| Parameter | HX300HD |
|---|---|
| Operating weight(kg) | 30200 |
| Engine power(kW/rpm) | 193 / 2200 |
| Bucket capacity(m³) | 1.5 |
| External dimensions(mm) | 10740*3200*3336 |
| Bucket rod digging force(kN) | 136.3 |
| Bucket digging force(kN) | 192.2 |
| Rotating speed(r/min) | 12.2 |
| Travel speed(km/h) | 6.1 |
| Maximum digging height(mm) | 10200 |
| Maximum digging distance(mm) | 10810 |
| Maximum digging depth(mm) | 7330 |
| Emissions (Indicated as per international standards) | ~TIER 2 |
