Key Specifications
Overview of the technical specifications.
Operating Weight
33 ton
Engine Power
193 kW / 2200 rpm
Bucket Capacity
1.74 m³
Track Shoe Width
600 mm
| Parameter | HX340HD |
|---|---|
| Operating weight(kg) | 33000 |
| Engine power(kW/rpm) | 193 / 2200 |
| Bucket capacity(m³) | 1.74 |
| External dimensions(mm) | 11220*3380*3360 |
| Bucket rod digging force(kN) | 145.1 |
| Bucket digging force(kN) | 216.7 |
| Rotating speed(r/min) | 11.2 |
| Travel speed(km/h) | 6.4 |
| Maximum digging height(mm) | 10360 |
| Maximum digging distance(mm) | 11150 |
| Maximum digging depth(mm) | 7360 |
| Emissions (Indicated as per international standards) | ~TIER 2 |
