Key Specifications
Overview of the technical specifications.
Operating Weight
77.7 ton
Engine Power
354 kW / 1800 rpm
Bucket Capacity
5.58 m³
Track Shoe Width
650 mm
| Parameter | HX800L |
|---|---|
| Operating weight(kg) | 77700 |
| Engine power(kW/rpm) | 354 / 1800 |
| Bucket capacity(m³) | 5.58 |
| External dimensions(mm) | 13165*3560*3530 |
| Bucket rod digging force(kN) | 287.3 |
| Bucket digging force(kN) | 341.3 |
| Rotating speed(r/min) | 7.5 |
| Travel speed(km/h) | 4.8 |
| Maximum digging height(mm) | 12120 |
| Maximum digging distance(mm) | 13195 |
| Maximum digging depth(mm) | 8345 |
| Emissions (Indicated as per international standards) | TIER 3 |
