Key Specifications
Overview of the technical specifications.
Operating Weight
12.1 ton
Engine Power
70 kW / 1950 rpm
Bucket Capacity
0.92 m³
Track Shoe Width
500 mm
| Parameter | R130S |
|---|---|
| Operating weight(kg) | 12100 |
| Engine power(kW/rpm) | 70 / 1950 |
| Bucket capacity(m³) | 0.45 / 0.65 |
| External dimensions(mm) | 7270*2490*2720 |
| Bucket rod digging force(kN) | 58.1 |
| Bucket digging force(kN) | 90.2 |
| Rotating speed(r/min) | 12 |
| Travel speed(km/h) | 3.4/5.5 |
| Maximum digging height(mm) | 8070 |
| Maximum digging distance(mm) | 7740 |
| Maximum digging depth(mm) | 5090 |
| Emissions (Indicated as per international standards) | ~TIER 2 |
