Key Specifications
Overview of the technical specifications.
Operating Weight
5.75 ton
Engine Power
42.5 kW / 2400 rpm
Bucket Capacity
0.21 m³
Wheelbase
2100 mm
| Parameter | R60WVS PRO |
|---|---|
| Operating weight(kg) | 5750 |
| Engine power(kW/rpm) | 42.5 / 2400 |
| Bucket capacity(m³) | 0.21 |
| External dimensions(mm) | 6100*1930*2850 |
| Bucket rod digging force(kN) | 32 |
| Bucket digging force(kN) | 42.5 |
| Rotating speed(r/min) | 10 |
| Travel speed(km/h) | 31 |
| Maximum digging height(mm) | 6070 |
| Maximum digging distance(mm) | 6150 |
| Maximum digging depth(mm) | 3500 |
| Emissions (Indicated as per international standards) | TIER 3 |
