Key Specifications
Overview of the technical specifications.
Operating Weight
56.2 ton
Engine Power
380 kW / 1800 rpm
Blade Capacity
13.7 m³
Track Shoe Width
610/660/710 mm
| Parameter | DH46-C3 RS |
|---|---|
| Operating weight(kg) | 56200 |
| Engine brand | Cummins |
| Rated power/rated speed(kW/rpm) | 391 / 1800 |
| Machine external dimensions(mm) | 9325*4320*3990 |
| Track center distance(mm) | 2260 |
| Track shoe width(mm) | 610/660/710 |
| Ground contact length(mm) | 3532 |
| Fuel tank capacity(L) | 920 |
| Blade type | ROCK |
| Blade capacity(m³) | 13.7 |
| Emissions (Indicated as per international standards) | Eu stageⅢA |
