Key Specifications
Overview of the technical specifications.
Operating Weight
16.81 ton
Engine Power
131 kW / 1850 rpm
Blade Capacity
3.5 m³
Track Shoe Width
560 mm
| Parameter | SD16E |
|---|---|
| Operating weight(kg) | 16810 |
| Engine brand | WEICHAI WD10G178E25 |
| Rated power/rated speed(kW/rpm) | 131 / 1850 |
| Machine external dimensions(mm) | 5345*3455*3205 |
| Track center distance(mm) | 1880 |
| Track shoe width(mm) | 560 |
| Ground contact length(mm) | 2635 |
| Fuel tank capacity(L) | 315 |
| Blade type | Straight tilting blade |
| Blade capacity(m³) | 4.5 |
| Emissions (Indicated as per international standards) | Eu stageⅡ |
