Key Specifications
Overview of the technical specifications.
Operating Weight
24.7 ton
Engine Power
175 kW / 1800 rpm
Blade Capacity
4.6 m³
Track Shoe Width
610/660 mm
| Parameter | SD22F |
|---|---|
| Operating weight(kg) | 24700 |
| Engine brand | Cummins / Weichai |
| Rated power/rated speed(kW/rpm) | 175/ 1800 |
| Machine external dimensions(mm) | 5495*3725*3402 |
| Track center distance(mm) | 2000 |
| Track shoe width(mm) | 610/660 |
| Ground contact length(mm) | 2730 |
| Fuel tank capacity(L) | 450 |
| Blade type | Straight tilting blade / Angle Blade / U-shaped Blade / Semi-U blade |
| Blade capacity(m³) | 4.6/3.4/5.8/6.7 |
| Emissions (Indicated as per international standards) | Eu stageⅡ |
