Key Specifications
Overview of the technical specifications.
Operating Weight
34.5 ton
Engine Power
257 kW / 2000 rpm
Blade Capacity
7.2 m³
Track Shoe Width
560 mm
| Parameter | SD32 |
|---|---|
| Operating weight(kg) | 34500 |
| Engine brand | Cummins |
| Rated power/rated speed(kW/rpm) | 257 / 2000 |
| Machine external dimensions(mm) | 8650*4130*3760 |
| Track center distance(mm) | 2140 |
| Track shoe width(mm) | 560 |
| Ground contact length(mm) | 3150 |
| Fuel tank capacity(L) | 640 |
| Blade type | Straight tilting blade / Angle Blade / Semi-U blade |
| Blade capacity(m³) | 7.2/4.8/9 |
| Emissions (Indicated as per international standards) | Eu stageⅡ |
