Key Specifications
Overview of the technical specifications.
Operating Weight
36 ton
Engine Power
258 kW / 2000 rpm
Blade Capacity
9 m³
Track Shoe Width
560/610/660/710 mm
| Parameter | SD34-C3XL |
|---|---|
| Operating weight(kg) | 36000 |
| Engine brand | WEICHAI |
| Rated power/rated speed(kW/rpm) | 258 / 2000 |
| Machine external dimensions(mm) | 9185*4130*3660 |
| Track center distance(mm) | 2140 |
| Track shoe width(mm) | 560/610/660/710 |
| Ground contact length(mm) | 3150 |
| Fuel tank capacity(L) | 620 |
| Blade type | Semi-U blade |
| Blade capacity(m³) | 10 |
| Emissions (Indicated as per international standards) | Eu stageⅢA |
