Key Specifications
Overview of the technical specifications.
Operating Weight
120 ton
Engine Power
680 kW / 1800 rpm
Bucket Capacity
7.5 m³
Track Shoe Width
700 mm
| Parameter | SE1250LC |
|---|---|
| Operating weight(kg) | 120000 |
| Engine power(kW/rpm) | 680 / 1800 |
| Bucket capacity(m³) | 7.5-10 (8.5 standard) |
| External dimensions(mm) | 14845*5385*4475 |
| Bucket rod digging force(kN) | 532 |
| Bucket digging force(kN) | 610 |
| Rotating speed(r/min) | 0-5.5 |
| Travel speed(km/h) | 2.4 / 3.5 |
| Maximum digging height(mm) | 12480 |
| Maximum digging distance(mm) | 13875 |
| Maximum digging depth(mm) | 8165 |
| Emissions (Indicated as per international standards) | Tier 4 |
