Key Specifications
Overview of the technical specifications.
Operating Weight
13.5 ton
Engine Power
92 kW / 2200 rpm
Bucket Capacity
0.6 m³
Track Shoe Width
500 mm
| Parameter | SE135W |
|---|---|
| Operating weight(kg) | 13500 |
| Engine power(kW/rpm) | 92 / 2200 |
| Bucket capacity(m³) | 0.6 |
| External dimensions(mm) | 7860*2500*2855 |
| Bucket rod digging force(kN) | 70 |
| Bucket digging force(kN) | 97 |
| Rotating speed(r/min) | 11.3 |
| Travel speed(km/h) | 3.25 / 5.2 |
| Maximum digging height(mm) | 8495 |
| Maximum digging distance(mm) | 8300 |
| Maximum digging depth(mm) | 5490 |
| Emissions (Indicated as per international standards) | EU Stage IIIA |
