Key Specifications
Overview of the technical specifications.
Operating Weight
150 ton
Engine Power
680 kW / 1800 rpm
Bucket Capacity
10 m³
Track Shoe Width
750 mm
| Parameter | SE1500LC |
|---|---|
| Operating weight(kg) | 150000 |
| Engine power(kW/rpm) | 680 / 1800 |
| Bucket capacity(m³) | 10 |
| External dimensions(mm) | 15660*5835*4740 |
| Bucket rod digging force(kN) | 560 |
| Bucket digging force(kN) | 630 |
| Rotating speed(r/min) | 0-4.5 |
| Travel speed(km/h) | 2.2 / 3.2 |
| Maximum digging height(mm) | 13470 |
| Maximum digging distance(mm) | 14060 |
| Maximum digging depth(mm) | 7700 |
| Emissions (Indicated as per international standards) | Tier 4 |
