Key Specifications
Overview of the technical specifications.
Operating Weight
21.5 ton
Engine Power
123 kW / 2200 rpm
Bucket Capacity
1 m³
Track Shoe Width
600 mm
| Parameter | SE210W |
|---|---|
| Operating weight(kg) | 21100 |
| Engine power(kW/rpm) | 116 / 2000 |
| Bucket capacity(m³) | 0.9 |
| External dimensions(mm) | 9543*2800*3039 |
| Bucket rod digging force(kN) | 99.5 |
| Bucket digging force(kN) | 135 |
| Rotating speed(r/min) | 0-11 |
| Travel speed(km/h) | 3.3 / 5.4 |
| Maximum digging height(mm) | 10029 |
| Maximum digging distance(mm) | 9860 |
| Maximum digging depth(mm) | 6541 |
| Emissions (Indicated as per international standards) | EU Stage IIIA |
