Key Specifications
Overview of the technical specifications.
Operating Weight
21.9 ton
Engine Power
140 kW / 2200 rpm
Bucket Capacity
1.06 m³
Track Shoe Width
600 mm
| Parameter | SE215W |
|---|---|
| Operating weight(kg) | 21900 |
| Engine power(kW/rpm) | 140 / 2000 |
| Bucket capacity(m³) | 1 |
| External dimensions(mm) | 9600*2980*3100 |
| Bucket rod digging force(kN) | 99 / 107 |
| Bucket digging force(kN) | 137 / 148 |
| Rotating speed(r/min) | 0-11 |
| Travel speed(km/h) | 3.7 / 5.3 |
| Maximum digging height(mm) | 10100 |
| Maximum digging distance(mm) | 9865 |
| Maximum digging depth(mm) | 6490 |
| Emissions (Indicated as per international standards) | EU Stage IIIA |
