Key Specifications
Overview of the technical specifications.
Operating Weight
76.5 ton
Engine Power
566 kW / 1900 rpm
Bucket Capacity
5 m³
Track Shoe Width
650 mm
| Parameter | SE800LCW |
|---|---|
| Operating weight(kg) | 76500 |
| Engine power(kW/rpm) | 566 / 1900 |
| Bucket capacity(m³) | 5 |
| External dimensions(mm) | 12600*4310*4700 |
| Bucket rod digging force(kN) | 350 |
| Bucket digging force(kN) | 420 |
| Rotating speed(r/min) | 0-7.2 |
| Travel speed(km/h) | 3.2 / 4.7 |
| Maximum digging height(mm) | 11820 |
| Maximum digging distance(mm) | 11700 |
| Maximum digging depth(mm) | 7150 |
| Emissions (Indicated as per international standards) | EU Stage IIIA |
